Stop leaks automatically—no power required
-
Cuts off the water feed instantly if a leak is detected inside the cooler cabinet—helps prevent puddles and damage.
-
Simple, mechanical design: a water‑activated pad swells and trips the shut‑off—no electricity or batteries to fail.
-
Fast reset: open the device, replace the wet pad with a dry one, and restore water flow. A spare pad is typically stored inside the unit.
Best for: offices, clinics, schools, and reception areas using the H2O‑2500 who want extra protection against internal leaks from fittings, filters, or tubing.
In the box & installation
- Included: Leak detector assembly for H2O‑2500 with activation pad; basic instructions. Pad quantity may vary by kit.
- Install / reset (summary from manual):
-
- Turn off the water feed and disconnect power.
- Remove the front bottom panel to access the device.
- If tripped, wipe up any water in the cabinet. Open the leak‑stop housing.
- Remove the wet expanded pad; insert a dry pad (a spare is typically stored inside the unit). Close housing.
- Restore water and power; check for leaks.
FAQs
Does this shut off the building water?
No, It shuts off water to the cooler itself. It’s designed to protect the H2O‑2500 cabinet and nearby area.
Where is the leak detector located?
Behind the lower front panel of the H2O‑2500; remove the panel for access.
How do I know it tripped?
The cooler stops receiving water. Open the front panel and check the device; replace the pad to reset.
What maintenance is needed?
Keep a spare dry pad on hand. After any activation, inspect fittings/tubing and fix the cause before resetting.
Is this compatible with both UF and RO builds?
Yes, the manual covers both and shows the same internal leak‑stop concept.
