SED-2000 | Ducted HEPA Air Filtration System for Large Smoking Areas - 1450-1650 CFM

For areas up to 2,000 sq. ft. HEPA filter combined with carbon is superior in capturing airborne particles and reducing odors. 1,450 - 1,650 CFM (2-speed). Installation hardware included.

First Year Filters Included!

SKU: SED-2000

Regular price
Sale price

The Powerful SED-2000 Ducted Filtration System Provides Excellent Clean Air Results in Large Smoking Areas

1,450 - 1,650 CFM (2-speed) for rooms or large smoking areas up to 2,000 sq. ft. Includes installation hardware PLUS all filters needed for the first year!

Designed for unobtrusive, ducted installation, the SED-2000 works effectively in areas up to 2,000 sq. ft. The SED Air Cleaner is suitable for homes, offices, or commercial establishments. It's not intended to be installed in line with existing HVAC ductwork but rather works independently with its own ducting configuration.

Installation options for the SED-2000 include;

Diagram of the SED-2000 Ducted HEPA Air Filtration System for Large Smoking Areas
  • Above a solid ceiling or suspended ceiling
  • In a basement, attic, or crawl space
  • In a utility room, furnace room, closet, etc.

Inflow and outflow air circulation can be customized to your specifications. Consult your HVAC contractor for installation and required ducting (not included). Its efficient multistage HEPA/Carbon filtering assures quality indoor air year-round. All 3 filters on the SED-2000 air cleaner are easily accessible. 1 unit recommended for every 10,000 cubic feet.

3-Filter System provides Excellent Air Filtration Results

The SED-2000 Concealed HEPA Filter System uses a powerful blower to draw the air from smoke-filled areas. As the air is drawn through the high-efficiency filter media, 95% of the tobacco smoke particles are removed on each pass. The clean air that is constantly discharged into the area is refreshing and remarkably free of tobacco smoke and other contaminants.

Stage 1 - Pre-Filter
The pre-filter is important because not only does it remove the larger particles, it also helps prolong the life of the HEPA filter in the system. Essentially, the pre-filter is the first line of defense in maintaining your system; therefore promoting better indoor air quality.
Twelve Polyester pre-filters are supplied with each system. Pre-filters cannot be washed and must be changed monthly.

Stage 2 - Activated Carbon Filter
Activated Carbon removes odors by absorbing odors, gases & VOC's into the filter. Think of carbon as an "odor sponge". It can hold many times its weight in odor molecules. However, once carbon becomes "saturated" it loses its efficiency. Thus, proper maintenance of the carbon filter is required to keep your environment fresh & clean smelling.
Six Activated Carbon Filter pads are supplied with each system. Carbon Filters cannot be washed and should be changed every 2 months.

Stage 3 - HEPA Filter
The HEPA filter removes the very small particles, such as smoke (tobacco, burning wood, oil, rosin), dust mites, spores, mold spores, pollen, spray paint, spray paint dust, ashes, cement dust, auto emissions, textile fibers, fiberglass, hairspray, insecticide dust, copier toner, and most viruses just to name a few. The HEPA filter is extremely important for superior air filtration and when used and maintained properly it will dramatically improve your indoor air quality. We cannot stress enough the importance of the HEPA filter to our system and the fact the HEPA filter must be maintained in order to achieve the maximum results.
One 12-inch HEPA Filter is supplied with each SED-2000 air cleaner. The HEPA filter cannot be washed and should be changed annually.

OPTIONAL - Factory Installed Remote Control

Optional Factory-Installed Remote Control is available for the SED-2000 Ducted Air Filtration System for Large Smoking AreasEasily control the settings on your SED-2000 Concealed Smoke Eater with a handy Remote Control Key Fob. It's an excellent choice for concealed systems. Each receiver is factory installed and comes with 2 battery-operated remote control key fobs. (Multiple air cleaners require a separate receiver/transmitter for each unit.) Receiver / Transmitter range is approximately 100 feet under normal operating conditions.

Features and Benefits of the SED-2000 Ducted HEPA Air Filter System

  • Powerful 2-Speed Blower - Effectively draws the air from polluted areas.
  • High-Efficiency Filter Media - Over 95% of the airborne particles are removed on each pass.
  • Refreshingly Clean Air - Virtually all of the smoke, pollen, dust, and other particles are removed from the air that passes through the SED-2000, including microscopic airborne particles.
  • Reduced Discomfort - Discharged air is cleaned of the many pollutants that can cause headaches, eye irritation, discomfort, and stuffiness.
  • Reduced Odors - Offensive odors including smoke residue that absorb into clothing, furniture, and carpeting are reduced.
  • Reduced Allergies & Asthma - Lowering the pollen, spores and fungi count helps to reduce allergies and asthma that may be caused by these contaminants.

SED-2000 Concealed HEPA Air Filtration System Specifications

Capacity Up to 2,000 Sq. Ft.
Two Speed (Toggle Switch) High - 1,650 CFM | Low - 1,450 CFM
Dimensions 48" (L) x 24" (W) x 24" (H)
Cabinet Construction 16 gauge gray steel cabinet
Shipping Weight 160 lbs.
Electrical 120V** | 9.0 Amps | 1/2 Hp Motor
Three Filter System Includes 1 Year Supply of Filters;
(1) 12-inch 95% HEPA Filter
(6) 1/2-inch Activated Carbon Filters
(12) 1/2-inch Pre-Filters
Warranty All Systems carry a 10-Year Blower/Motor Warranty*
Certifications Fan motor and all electrical components are UL Listed and CSA Certified
*10-Year Blower/Motor warranty applies if filters are changed as required and are purchased from Pure n Natural Systems, Inc.
** The SED-2000 concealed air cleaner is designed to be wired to a 120 VAC power source. Wiring connections are located in the junction box on top of each unit. All wiring shall meet local codes.
NOTE: The SED series is designed for contractor-installed ducted use. At a minimum, there should be at least one supply and one return per unit. Contact your local HVAC Contractor for installation and required ducting (not included).
NOTE: The SED-2000 is equipped with 4 eye bolts installed on each system. Also included are 4 "S" hooks and 20' industrial hanging wire.
This item ships by freight truck. Please refer to our shipping policy by clicking here.
